High Temperature Clear Gloss Paint
Thurmalox 293 Clear
Thurmalox 293 is a heat-resistant, fast-drying, silicone-based clear lacquer formulated to prevent tarnishing, discoloration and finger printing of metal parts used at elevated temperatures on items such as woodstoves, fireplace closures and other OEM applications. Thurmalox 293 fills the need for a finish which retains its clarity to 650°F (343°C) and its film integrity to 1000°F (538 °C).
TECHNICAL DATA
|
Characteristics
|
Thurmalox 293
|
|
Generic Type
|
Silicone
|
|
Color
|
Clear
|
|
Finish
|
Gloss
|
|
Temperature resistance
|
|
|
Continuous
|
1,000°F (538°C)
|
|
Gloss retention
|
500°F (260°C)
|
|
% solids by volume
|
16.0
|
|
Viscosity
|
35-40 sec. Zahn No. 4 cup
|
|
Dry film thickness per coat
|
0.75 - 1.0 mils (19 - 25 microns)
|
|
Wet film thickness per coat
|
4- 5 mils (100 - 125 microns)
|
|
Theoretical coverage per gallon
|
255 mil. sq. ft. (23.7 sq. m. @ 25 microns)
|
|
Application temperature @ 50% RH
|
60-90° F (16-32° C)
|
|
Drying time @ 70° F (21° C) 50% RH
|
|
|
To touch
|
15-20 minutes
|
|
To handle
|
20-30 minutes
|
|
To recoat
|
1-2 hours
|
|
Weight per gallon
|
|
|
Thurmalox 293
|
7.72 lb. (3.5 kg.)
|
|
Dampney 100 Thinner
|
7.1 lb. (3.2 kg.)
|
|
Flash point (Pensky Martens)
|
45°F (7°C)
|
|
Pot life
|
N/A
|
|
Shelf life
|
1 year
|
|
Volatile organic compounds
|
6.1 lb./gal. (731 g./l.)
|
